Ceramic Hybrid Roller Bearings High Precision 3.15gcm3

Brand Name : CSQ

Model Number : Customized

Place of Origin : China

MOQ : 50 pcs

Price : Negotiable

Payment Terms : T/T

Supply Ability : Negotiable

Delivery Time : Negotiable

Packaging Details : Plastik box+carton box

Name : Hybrid Ceramic Roller Bearing

Model : Customized

Category : Hybrid ceramic bearing

Precision : Customized, according to your need

Races Material : Steel

Roller material : ZrO2/Si3N4/SSiC

MOQ : 50 pieces

Pacage : Plastik box+carton box

Contact Now

Customized Hybrid Ceramic Roller Bearing With High Precision

Description of Hybrid Ceramic Roller Bearing:

As professional ceramic bearing manufacture in China, ur company can customize hybrid ceramic roller bearings of many models too. The material of races can be chosen among stainless steel or bearing steel and assembled with ceramic rollers of zirconia, silicon nitride and silicon carbide. The hybrid ceramic roller bearing combines the nice wear resistance of steel and the excellent resistance to corrosion. Welcome your inquiry

Material properties of ceramic rollers:

Material Properties	Units	SSiC	HIP-Si₃N₄	GPS-Si₃N₄	HIP-ZrO₂
Density	g/cm³	3.15-3.18	3.27-3.29	3.22-3.27	6.05-6.09
Porosity	%	0	0	0	0
Fledural Strength	MPa	550	830	689	900
Elastic Modulus	GPa	410	310	310	200
Hardness	HV5	2800	1580	1450	1300
Fracture Toughness KIC	MPa.m^1/2	4.6	6.1	5.7	8-11
Maximum Use Temperature	℃ (℉)	1650 (3000)	1000 (1830)	1000 (1830)	380 (716)
